Camera
Image Sensor
1/2.8" CMOS
Effective Pixels
1945(H)×1097(V), 2.1MP
Scanning System
Progressive
Electronic Shutter Speed
PAL: 1.3s~1/30000s
NTSC: 1s~1/30000s
Minimum Illumination
0.005Lux/F1.2 (Color), 0.0005Lux/F1.2 (B/W)
S/N Ratio
More than 65dB
IR Distance
N/A
IR On/Off Control
IR LEDs
Lens
Lens Type
C/CS lens / Auto iris
Mount Type
C/CS
Focal Length
Max Aperture
Angle of View
Focus Control
Auto / Manual
Close Focus Distance
Pan / Tilt / Rotation
Pan/Tilt/Rotation
Video
Resolution
1080P (1920×1080)
Frame Rate
25/30fps@1080P, 25/30/50/60fps@720P
Video Output
1-channel BNC HDCVI high definition video output & 1-channel BNC CVBS video output
Day/Night
Auto (ICR) / Manual
OSD Menu
Multi-language
BLC Mode
BLC / HLC / WDR
WDR
120dB
Gain Control
AGC
Noise Reduction
2D / 3D
White Balance
Smart IR
Certifications
CE (EN55032, EN55024, EN50130-4)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Interface
Audio Interface
1-channel audio in
Alarm Interface
2-channel alarm in & 1-channel alarm out
Eelectrical
Power Supply
AC 24V±25% / DC 12V±25%
Power Consumption
Max 4.7W (12V DC, IR on)
Environmental
Operating Conditions
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
* Start up should be done at above -30°C (-22°F)
Storage Conditions
Ingress Protection & Vandal Resistance
Construction
Casing
Aluminium
Dimensions
135.4mm×74.4mm×65.5mm (5.33"×2.93"×2.58")
Net Weight
0.49kg (1.08lb)
Gross Weight
0.60kg (1.32lb)
