Camera
|
Image Sensor
|
1/2.7" CMOS
|
Effective Pixels
|
1928(H)×1088(V), 2.1MP
|
Scanning System
|
Progressive
|
Electronic Shutter Speed
|
PAL: 1.3s~1/30000s
NTSC: 1s~1/30000s
|
Minimum Illumination
|
0.03Lux/F2.0, 30IRE, 0Lux IR on
|
S/N Ratio
|
More than 65dB
|
IR Distance
|
Up to 80m (262feet)
|
IR On/Off Control
|
Auto / Manual
|
IR LEDs
|
2
|
Lens
|
Lens Type
|
Fixed lens / Fixed iris
|
Mount Type
|
Board-in
|
Focal Length
|
3.6mm (6mm, 8mm, 12mm Optional)
|
Max Aperture
|
F2.0
|
Angle of View
|
H: 90° (59.4°/41.4°/26.5° )
|
Focus Control
|
N/A
|
Close Focus Distance
|
800mm (1800mm, 3000mm, 8400mm)
31.50'' ( 70.87'', 118.11'', 330.71'')
|
Pan / Tilt / Rotation
|
Pan/Tilt/Rotation
|
Pan: 0° ~ 360°
Tilt: 0° ~ 87°
Rotation: 0° ~ 360°
|
Video
|
Resolution
|
1080P (1920×1080)
|
Frame Rate
|
25/30fps@1080P, 25/30/50/60fps@720P
|
Video Output
|
1-channel BNC HDCVI high definition video output & 1-channel BNC CVBS video output
|
Day/Night
|
Auto (ICR) / Manual
|
OSD Menu
|
Multi-language
|
BLC Mode
|
BLC / HLC / WDR
|
WDR
|
120dB
|
Gain Control
|
AGC
|
Noise Reduction
|
2D / 3D
|
White Balance
|
Auto / Manual
|
Smart IR
|
Auto / Manual
|
