Camera
|
Image Sensor
|
1/3” 4Megapixel progressive scan CMOS
|
Effective Pixels
|
2688(H)x1520(V)
|
RAM/ROM
|
512MB/32MB
|
Scanning System
|
Progressive
|
Electronic Shutter Speed
|
Auto/Manual, 1/3~1/100000s
|
Minimum Illumination
|
0.03Lux/F1.4 (Color,1/3s,30IRE)
0.3Lux/F1.4 (Color,1/30s,30IRE)
0Lux/F1.4(IR on)
|
S/N Ratio
|
More than 50dB
|
IR Distance
|
Distance up to 100m (328ft)
|
IR On/Off Control
|
Auto/ Manual
|
IR LEDs
|
3
|
Lens
|
Lens Type
|
Motorized/ Auto Iris(HALL)
|
Mount Type
|
Board-in
|
Focal Length
|
7mm~35mm
|
Max. Aperture
|
F1.4
|
Angle of View
|
H: 32°~10° , V:18°~6°
|
Optical Zoom
|
5x
|
Focus Control
|
Motorized
|
Close Focus Distance
|
0.4m
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
W
|
190m(623ft)
|
76m(249ft)
|
38m(124ft)
|
19m(62ft)
|
T
|
620m(2034ft)
|
248m(813ft)
|
124m(406ft)
|
62m(203ft)
|
Pan/Tilt/Rotation
|
Pan/Tilt/Rotation Range
|
Pan:0˚~355˚; Tilt:0˚~65˚; Rotation:0˚~355˚
|
Intelligence
|
IVS
|
Tripwire, Intrusion, Object Abandoned/Missing
|
Advanced Intelligent Functions
|
Face Detection
|
Video
|
Compression
|
H.265+/H.265/H.264+/H.264
|
Streaming Capability
|
3 Streams
|
Resolution
|
4M(2688x1520)/3M(2304x1296)/
1080P(1920x1080)/1.3M(1280×960)/
720P(1280×720)/D1(704×576/704×480)/
VGA(640×480)/CIF(352×288/352×240)
|
Frame Rate
|
Main Stream: 4M(1~25/30fps)
|
Sub Stream: D1(1~25/30fps)
|
Third Stream: 720P(1~25/30fps)
|
Bit Rate Control
|
CBR/VBR
|
Bit Rate
|
H.264: 24~10240Kbps
H.265: 14~9984Kbps
|
