| Camera |
| Matrix |
3 Mp, 1/3 "Aptina CMOS |
Effective pixels
|
2048 (H) x 1536 (V) |
| Scanning system |
Progressive |
| Electronic Shutter Speed |
Auto / Manual, 1/3 ~ 1 / 10000c |
| Min. lighting |
Color: 0.1 Lux / F1.2, B / W: 0.01 Lux / F1.2; 0 lux / F1.2 (Ik on) |
| S / N Ratio |
More than 50dB |
| Video output |
1 channel BNC (1.0 Vp-p, 75Ω) |
| Camera Features |
| Illumination Illumination Range |
30 meters, Smart Ik technology |
| Day Night |
Auto (ICR) / Color / B & W |
| Backlight Compensations |
BLC / HLC / WDR 120dB |
| White balance |
Auto / Manual |
| Gain control |
Auto / Manual |
| Noise Reduction |
3D DNR |
| Private masks |
up to 4 zones |
| EIS (Electronic Image Stabilization) |
Supported by |
| Ultra Defog (anti-fog) |
Supported by |
| Lens |
| Focal length |
2.7 - 12 mm |
| Max. aperture |
F1.4 |
| Focus Management |
Manual |
| Viewing Angle |
H: 82 ° ~ 25 ° |
| Lens Management |
Auto diaphragm (DC) / manual |
| Mounting type |
On board |
| Video |
| Compression |
H.264 / MJPEG |
| Resolution |
3 Mp (2048x1536) / 1080p (1920x1080) / 720p (1280x720) / D1 (704x576) / CIF (352x288) |
| Recording |
Main stream: 3Mp / 1080p (1-25 fps) |
| Additional stream: D1 / CIF (1-25 frames / s) |
| Third stream: 1080p / 720p / D1 (1-25 fps) |
| Flow |
H.264: 48K ~ 8192 Kbps |
| ROI |
up to 4 zones |
| Audio |
| Compression |
G.711a / G.711u |
| Interface |
1 input / 1 output |
| Smart Features |
| Video analytics |
Intrusion detection |
| Detection of the barrier |
| Detection of abandoned and lost objects |
| Detection of the direction of travel |
| Audio detection |
| Face Recognition |
| Net |
| Interface |
RJ-45 10/100/1000 Base-T |
| Protocols |
IPv4 / IPv6, HTTP, HTTPS, SSL, TCP / IP, UDP, UPnP, ICMP, IGMP, SNMP, RTP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour |
| Compatibility |
ONVIF, PSIA, CGI |
| Max. number of users |
20 Users |
| Mobile platforms |
iPhone, iPad, Android, Windows Phone |
| Other Interfaces |
| Memory Slot |
Micro SD, up to 64GB |
| Anxiety |
1 input / 1 output |
| Basic |
| Food |
DC 12V, PoE (802.3af) |
| Consumption |
Max. 12W |
| Operating temperatures |
-20 ° C ~ + 60 ° C, Less than 90% RH |
| Degree of protection |
IP66, IK10 |
| The size |
F151x119 mm |
| The weight |
1.3 Kg |
