Standard :
|
TCP / IP
|
|
Transducer :
|
1/3 "Progressive Scan CMOS
|
|
Matrix size :
|
3.0 Mpx
|
|
Scan system :
|
Progressive
|
|
Resolution :
|
2304 x 1296 - 3.0 Mpx ,
1920 x 1080 - 1080p
1280 x 960 - 1.3 Mpx
1280 x 720 - 720p
640 x 480 - VGA
|
|
Operating modes :
|
The main and auxiliary streams can be in any configuration
Firmware 2.400.0000.5.R, build: 2016-07-01
Main stream: 2304 x 1296, 1920 x 1080, 1280 x 960, 1280 x 720, 640 x 480
Auxiliary stream: 640 x 480, 320 x 240
|
|
Lens :
|
2.8 mm
|
|
Angle of view :
|
100 ° (manufacturer's specifications)
98 ° (our tests)
|
|
IR illuminator range :
|
30 m
|
|
Signal / noise ratio (S / N) :
|
> 50 dB
|
|
RS-485 interface :
|
N/A
|
|
Image compression method :
|
H.264H / H.264B / H.264 / MJPEG
|
|
Alarm inputs / outputs :
|
N/A
|
|
Audio :
|
N/A
|
|
Bitrate :
|
448 kbit / s ... 10240 kbit / s - H.264
|
|
Transmission speed of the main stream :
|
20 fps @ 3.0 Mpx
25 fps @ 1080p
|
|
Network interface :
|
10/100 Base-T (RJ-45)
|
|
Network protocols :
|
IPv4 / IPv6, HTTP, HTTPS, TCP / IP, UDP, UPnP, ICMP, IGMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS
|
|
WEB Server :
|
Built-in
|
|
Max. Number of on-line users :
|
20
|
|
ONVIF :
|
2.42
|
|
Memory card slot :
|
Support for Micro SD cards up to 128GB (local record possible)
|
|
Selected functions :
|
Wi-Fi module - IEEE 802.11 b / g / n, Range: 50 m (open space); Antenna - SMA socket
D-WDR - A wide range of lighting dynamics
3D-DNR - Digital noise reduction in the image
BLC / HLC - background / strong light compensation
The ability to change resolution, quality and bandwidth
Motion detection
Configurable privacy zone
Mirror - Mirror image
|
|
Power supply :
|
12 V DC / 360 mA
|
|
Power consumption :
|
≤ 4.4 W
|
|
Access from a mobile phone :
|
Port: 37777 or access via cloud (P2P)
Android: Free application gDMSS Lite , Android: Free application Easy4ip
iOS (iPhone): Free application iDMSS Lite , iOS (iPhone): Free application Easy4ip
|
|
Default administrator login / password :
|
admin / admin
|
|
Default IP address :
|
192.168.1.108
|
|
Internet access ports :
|
80, 37777
|
|
Access ports via the application on the PC :
|
37777
|
|
Access port through a mobile application :
|
37777
|
|
ONVIF port :
|
80
|
|
RTSP URL :
|
rtsp: // admin: admin@192.168.1.108: 554 / cam / realmonitor? Channel = 1 & subtype = 0 - Main stream
rtsp: // admin: admin@192.168.1.108: 554 / cam / realmonitor? channel = 1 & subtype = 1 - Auxiliary stream
|
|
Housing :
|
Compact - Metal
|
|
Color :
|
White
|
|
Tightness class :
|
IP67
|
|
Working temperature :
|
-10 ° C ... 50 ° C
|
|
Weight :
|
0.428 kg
|
|
Dimensions :
|
165 x 70 x 70 mm
|
|
Supported languages :
|
English Polish
|
|
Producer / Brand :
|
DAHUA
|
