Image Sensor
1/3” 3Megapixel progressive scan Aptina CMOS
Effective Pixels
2048(H)x1536(V)
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1/3(4)~1/10000s
Min. Illumination
0.01Lux/F1.4(Color), 0Lux/F1.4(IR on)
S/N Ratio
More than 50dB
Camera Features
Max. IR LEDs Length
30m
Day/Night
Auto(ICR) / Color / B/W
Backlight Compensation
BLC / HLC / DWDR
White Balance
Auto/Manual
Gain Control
Noise Reduction
3D
Privacy Masking
Up to 4 areas
Lens
Focal Length
2.8~12mm motorized
Max Aperture
F1.4
Focus Control
Auto
Angle of View
H: 92°~28°
Lens Type
Motorized/ Auto Iris(DC)
Mount Type
Board-in Type
Video
Compression
H.264/MJPEG
Resolution
3M(2048×1536)/1080P(1920×1080)/720P(1280×720)/D1(704×576/704×480)/CIF(352×288/352×240)
Frame Rate
Main Stream
3M(1~20fps)/1080P/720P(1 ~ 25/30fps)
Sub Stream
D1/CIF(1 ~ 25/30fps)
Bit Rate
H.264: 32K ~ 8192Kbps
Audio
N/A
Interface
Network
Ethernet
RJ-45 (10/100Base-T)
Wi-Fi
Protocol
IPv4/IPv6, HTTPS, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
Compatibility
ONVIF,PSIA,CGI
Max. User Access
20users
Smart Phone
iPhone, iPad, Android, Windows Phone
Auxiliary Interface
Memory Slot
RS485
Alarm
PIR Sensor Range
General
Power Supply
DC12V, PoE(802.3af)
Power Consumption
Max 7.5W (-H: +2W, Motorized lens: +2W)
Working Environment
-30°C~+60°C(-H: -40°C~+60°C), Less than 95%RH
Ingress Protection
IP66
Vandal Resistance
Dimensions
273.3mm × 94.8mm× 94.8mm
Weight
1.25kg(1.66kg with packaging)
