Standard:
|
TCP / IP
|
|
Converter:
|
1 / 2.7 "Progressive Scan CMOS
|
|
Matrix size:
|
2.0 Mpx
|
|
Resolution:
|
1920 x 1080 - 1080p
1280 x 1024 - 1.4 Mpx
1280 x 960 - 1.3 Mpx
1280 x 720 - 720p
704 x 576 - D1
|
|
Modes of operation:
|
The main and auxiliary streams can be in any configuration
Firmware 2.400.0000.15.R, build: 2015-08-30
- Main stream: 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 704 x 576
- Auxiliary stream: 704 x 576, 352 x 288
|
|
Lens:
|
2.7 ... 12 mm - Motozoom
|
|
Angle of view:
|
- 99 ° ... 34 ° (according to the manufacturer)
- 88 ° ... 34 ° (our tests)
|
|
IR illuminator range:
|
50 m
|
|
Signal / noise ratio (S / N):
|
> 50 dB (AGC excluded)
|
|
Compression:
|
H.264 / MJPEG
|
|
Bitrate:
|
224 ... 10240 kbit / s - H.264
|
|
Transmission speed of the main stream:
|
25 fps - 1080p
|
|
Network interface:
|
10/100 Base-T (RJ-45)
|
|
Network protocols:
|
IPv4 / IPv6, HTTP, HTTPS, SSL, TCP / IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
|
|
WEB Server:
|
Built-in, Compatibility with NVR
|
|
Max. Number of on-line users:
|
20
|
|
ONVIF:
|
2.42
|
|
Alarm inputs / outputs:
|
2/1
|
|
Audio:
|
- Entrance to an external microphone
- Audio output
- Supports bi-directional audio
- Sound detection
|
|
RS-485 interface:
|
-
|
|
Access from a mobile phone:
|
Port 37777
- Android: Free application gDMSS Lite
- iOS (iPhone): Free iDMSS Lite application
- Windows Phone: Free application in DMSS Lite
There are also paid versions of mobile applications: gDMSS Plus, iDMSS Plus, wDMSS plus
|
|
Power supply:
|
- PoE (802.3af),
- 12 V DC / 940 mA
|
|
Selected functions:
|
- ICR - Mechanical infrared filter
- DNR - Digital noise reduction in the image
- AGC - Automatic adjustment of image enhancement
- ABF - (Auto Back Focus) - automatic focus correction when switching day / night modes
- WB - White balance (ATW / AWB / manual / internal / external)
- WDR - A wide range of lighting dynamics
- BLC - configurable backlight compensation
- HLC - High light (spot) compensation
- Day / night mode (color / b & w / auto)
- Sound detection
- IVS analysis - detection of line crossing, intrusion, scene changes, abandoned / missing object, face detection
- Motion detection
- Configurable privacy zone
- Mirror - Mirror image
- Sharpness - Sharpens the outlines of the image
|
|
Housing:
|
Compact, Metal / Plastic
|
|
Colour:
|
White
|
|
Tightness class:
|
IP67
|
|
Working temperature:
|
-30 ° C ... 60 ° C
|
|
Weight:
|
0.992 kg
|
|
dimensions:
|
274 x 95 x 95 mm
|
