Standard :
|
TCP / IP
|
|
Transducer :
|
1 / 2.8 "STARVIS ™ CMOS
|
|
Matrix size :
|
2.1 Mpx
|
|
Resolution :
|
1920 x 1080 - 1080p
1280 x 1024 - 1.4 Mpx
1280 x 960 - 1.3 Mpx
1280 x 720 - 720p
|
|
Operating modes :
|
The main and auxiliary streams can be in any configuration
Firmware 2.400.0000.23.R bulid: 2016-07-05
· Main stream: 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720
· Auxiliary stream: 704 x 576, 352 x 288
· Auxiliary stream 2: 1280x720, 704x57, 352x288
|
|
Lens :
|
2.7 ... 12 mm - Motozoom
|
|
Angle of view :
|
· 97 ° ... 34 ° (according to the manufacturer)
· 92 ° ... 33 ° (our tests)
|
|
Compression :
|
H.265 / H.264 / MJPEG
|
|
Signal / noise ratio (S / N) :
|
> 50 dB (AGC excluded)
|
|
IR illuminator range :
|
50 m
|
|
Alarm inputs / outputs :
|
2/1
|
|
Bitrate :
|
24 ... 9472 kbit / s - H.264
14 ... 5632 kbit / s - H.265
|
|
Transmission speed of the main stream :
|
50 fps @ 1080p
|
|
Audio :
|
· Entrance to an external microphone
· Audio output
· Supports bi-directional audio
· Sound detection
|
|
Memory card slot :
|
Support for Micro SD cards up to 128GB (local record possible)
|
|
Network interface :
|
10/100 Base-T (RJ-45)
|
|
Network protocols :
|
IPv4 / IPv6, HTTP, HTTPS, SSL, TCP / IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
|
|
Access from a mobile phone :
|
Port: 37777 or access via cloud (P2P)
· Android: Free application gDMSS Lite , Android: Free application Easy4ip
· iOS (iPhone): Free application iDMSS Lite , iOS (iPhone): Free application Easy4ip
There are also paid versions of mobile applications: gDMSS Plus, iDMSS Plus
|
|
Default administrator login / password :
|
admin / admin
|
|
Default IP address :
|
192.168.1.108
|
|
Internet access ports :
|
80, 37777
|
|
Access ports via the application on the PC :
|
37777
|
|
WEB Server :
|
Built-in, Compatibility with NVR
|
|
Access port through a mobile application :
|
37777
|
|
Max. Number of on-line users :
|
20
|
|
ONVIF :
|
2.42
|
|
ONVIF port :
|
80
|
|
RTSP URL :
|
rtsp: // admin: admin@192.168.1.108: 554 / cam / realmonitor? channel = 1 & subtype = 0 - Main stream
rtsp: // admin: admin@192.168.1.108: 554 / cam / realmonitor? channel = 1 & subtype = 1 - Auxiliary stream
|
|
RS-485 interface :
|
|
|
Selected functions :
|
· ICR - Mechanical infrared filter
· WDR - 120 dB - Wide range of lighting dynamics
· 3D-DNR - Digital noise reduction in the image
· AGC - Automatic adjustment of image enhancement
· WB - White balance (ATW / AWB / manual / internal / external)
· BLC - configurable backlight compensation
· HLC - High light (spot) compensation
· Day / night mode (color / b & w / auto)
· Sound detection
· IVS analysis - intrusion , line crossing , scene change , abandoned / missing object , face detection
· Sound detection
· Motion detection
· Configurable privacy zone
· Mirror - Mirror image
· Sharpness - Sharpens the outlines of the image
|
|
Power consumption :
|
<11.5 W
|
|
Working temperature :
|
-30 ° C ... 60 ° C
|
|
Color :
|
White
|
|
Tightness class :
|
IP67
|
|
Power supply :
|
· PoE (802.3af) ,
· 12 V DC / 940 mA
|
|
Housing :
|
Compact, Metal / Plastic
|
|
Supported languages :
|
English Polish
|
|
Producer / Brand :
|
DAHUA
|
|
Weight :
|
1.066 kg
|
|
Dimensions :
|
273 x 95 x 96 mm
|
