Model
DH-IPC-HFW5300CP
System
CPU
High performance embedded microprocessor
operating system
Built-in LINUX
System Resources
remote monitoring, local and remote recording
Camera
Matrix
1/3 "3.0 Mp progressive scan Exmor CMOS
Effective pixels
2048 (H) x1536 (V)
Electronic shutter
Auto / Manual, 1/3 ~ 1 / 10,000s
Min. sensitivity
0.01 Lux / F1.4 (Color), 0 Lux (IR on)
S / N Ratio
> 50dB
Gain control
Auto / Manual
White balance
Day / Night Mode
ICR
Lens
Automatic aperture, f = 2.7-12mm / F1.2
Private masks
up to 4 zones
Noise suppression
3D DNR
Video
Video compression
H.264 / H.264H / MJPEG
Image resolution
3.0M (2048x1536) 1080P (1920x1080) SXGA (1280x1024) 1.3M (1280x960) 720P (1280x720) D1 (704x576) CIF (352x288)
Encoding Speed
Main stream: 3M (1 ~ 20k / s.), 1080p / 720p (1 ~ 25fps).
Additional flow: D1 (1 ~ 25fps)
Transmission speed
56Kbps ~ 8192Kbps
Snapshot
Fast capture of 1 frame / s. JPEG
Video format
PAL
Net
Ethernet
RJ-45 (10 / 100Base-T)
Network function
HTTP, TCP / IP, ARP, IGMP, ICMP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, Bonjour, SNMP
Remote work
Monitoring, PTZ control, playback, system setup, file downloads, information, maintenance and upgrade
Specifications
Power supply
DC 12V, PoE (802.3af)
Power Consumption
7.5W
IR illumination range
30 meters
Degree of protection
IP 66
Working temperature
-30 ° C ~ + 60 ° C
Dimensions
ф104 x 306mm
The weight
1.25 kg
