Standard :
|
TCP / IP
|
|
Transducer :
|
1/3 "Progressive Scan CMOS
|
|
Matrix size :
|
4.0 Mpx
|
|
Scan system :
|
Progressive
|
|
Resolution :
|
2688 x 1520 - 4.0 Mpx ,
2560 x 1440 - 3.6 Mpx ,
2304 x 1296 - 3.0 Mpx ,
1920 x 1080 - 1080p
1280 x 1024 - 1.4 Mpx
1280 x 960 - 1.3 Mpx
1280 x 720 - 720p
|
|
Operating modes :
|
Main and auxiliary streams can exist in any configuration.
Firmware 2.460.0000.1.R bulid: 2016-10-25
· Main stream: 2688 x 1520, 2560 x 1440, 2304 x 1296, 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720
· Auxiliary stream: 704 x 576, 352 x 288
· Auxiliary stream 2: 1280x720, 704x57, 352x288
|
|
Lens :
|
6 mm
|
|
Angle of view :
|
· 55 ° (manufacturer information)
· 58 ° (our tests)
|
|
IR illuminator range :
|
80 m
|
|
Signal / noise ratio (S / N) :
|
> 50 dB
|
|
RS-485 interface :
|
|
|
Memory card slot :
|
Micro SD card support up to 128GB (local record possible)
|
|
Image compression method :
|
H.265 / H.264 / MJPEG
|
|
Alarm inputs / outputs :
|
1/1
|
|
Audio :
|
· Entrance to an external microphone
· Audio output
· Sound detection
|
|
Bitrate :
|
· 384 kbit / s ... 10240 kbit / s - H.264
· 14 kbit / s ... 5632 kbit / s - H.265
|
|
Transmission speed of the main stream :
|
25 fps @ 4.0 Mpx
|
|
Network interface :
|
10/100 Base-T (RJ-45)
|
|
Network protocols :
|
IPv4 / IPv6, HTTP, HTTPS, SSL, TCP / IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
|
|
WEB Server :
|
Built-in
|
|
Max. Number of on-line users :
|
20
|
|
ONVIF :
|
2.42
|
|
Access from a mobile phone :
|
Port: 37777 or access via cloud (P2P)
· Android: Free application gDMSS Lite , Android: Free application Easy4ip
· iOS (iPhone): Free application iDMSS Lite , iOS (iPhone): Free application Easy4ip
|
|
Default administrator login / password :
|
admin / admin
|
|
Default IP address :
|
192.168.1.108
|
|
Internet access ports :
|
80, 37777
|
|
Access ports via the application on the PC :
|
37777
|
|
Access port through a mobile application :
|
37777
|
|
ONVIF port :
|
80
|
|
RTSP URL :
|
rtsp: // admin: admin@192.168.1.108: 554 / cam / realmonitor? channel = 1 & subtype = 0 - Main stream
rtsp: // admin: admin@192.168.1.108: 554 / cam / realmonitor? channel = 1 & subtype = 1 - Auxiliary stream
|
|
Selected functions :
|
· 3D-DNR - Digital noise reduction in the image
· WDR - 120 dB - Wide range of lighting dynamics
· ICR - Mechanical infrared filter
· IVS analysis : line crossing , intrusion , scene change , abandoned / missing object , face detection
· Sound detection
· Configurable privacy zone
· D-ZOOM - Digital zoom
· BLC / HLC - background / strong light compensation
· The ability to change resolution, quality and bandwidth
· Mirror - Mirror image
|
|
Power supply :
|
· PoE (802.3af) ,
· 12 V DC / 620 mA
|
|
Power consumption :
|
≤ 7.5 W
|
|
Housing :
|
Compact - Metal / Plastic
|
|
Color :
|
White
|
|
Tightness class :
|
IP67
|
|
Working temperature :
|
-30 ° C ... 60 ° C
|
|
Weight :
|
0.716 kg
|
|
Dimensions :
|
242 x 90 x 90 mm
|
