Standard:
|
TCP/IP
|
|
Sensor:
|
1/2.5 " Progressive Scan CMOS
|
|
Matrix size:
|
8.8 Mpx
|
|
Resolution:
|
3840 x 2160 - 8.3 Mpx ,
3072 x 2048 - 6.3 Mpx ,
3072 x 1728 - 5.3 Mpx ,
2592 x 1944 - 5.0 Mpx ,
2688 x 1520 - 4.0 Mpx ,
2560 x 1440 - 3.7 Mpx ,
2304 x 1296 - 3 Mpx ,
1920 x 1080 - 1080p ,
1280 x 1024 - 1.4 Mpx ,
1280 x 960 - 1.3 Mpx ,
1280 x 720 - 720p
|
|
Operation modes:
|
Main and sub streams may be in any configuration
Firmware 2.400.0000.23.R bulid: 2016-07-05
· Main stream : 3840 x 2160, 3072 x 2048, 3072 x 1728, 2592 x 1944, 2688 x 1520, 2560 x 1440, 2304 x 1296, 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720
· Sub stream 1 : 704 x 576, 352 x 288
· Sub stream 2 : 1280 x 720, 704 x 576
|
|
Scanning system:
|
Progressive
|
|
Lens:
|
4 mm
|
|
View angle:
|
87 °
|
|
Range of IR illumination:
|
40 m
|
|
S/N ratio:
|
> 50 dB
|
|
RS-485 interface:
|
|
|
Memory card slot:
|
|
|
Image compression method:
|
H.265 / H.264 / MJPEG
|
|
Alarm inputs / outputs:
|
|
|
Audio:
|
|
|
Bitrate:
|
24 kb/s ... 10240 kb/s - H.264
14 kb/s ... 9984 kb/s - H.265
|
|
Main stream frame rate:
|
15 fps @ 8.8 Mpx
20 fps @ 6.3 Mpx
25 fps @ 5.3 Mpx
|
|
Network interface:
|
10/100 Base-T (RJ-45)
|
|
Network protocols:
|
IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
|
|
WEB Server:
|
Built-in
|
|
Max. number of on-line users:
|
20
|
|
ONVIF:
|
2.42
|
|
Main features:
|
· 3D-DNR - Digital Noise Reduction
· D-WDR - Wide Dynamic Range
· ICR - Movable InfraRed filter
· BLC/HLC - Back Light / High Light Compensation
· Possibility to change the resolution, quality and bit rate
· Configurable Privacy Zones
· Motion Detection
· Mirror - Mirror image
· IVS analysis : crossing the line (tripwire), scene changing, intrusion, abandoned/missing object, face detection
|
|
Power supply:
|
· PoE (802.3af),
· 12 V DC / 580 mA
|
|
Power consumption:
|
< 7 W
|
|
Mobile phones support:
|
Port no.: 37777 or access by a cloud (P2P)
· Android: Free application gDMSS Lite, Android: Free application Easy4ip
· iOS (iPhone): Free application iDMSS Lite, iOS (iPhone): Free application Easy4ip
There are also paid versions of mobile applications: gDMSS Plus, iDMSS Plus
|
|
Default admin user / password:
|
admin / admin
|
|
Default IP address:
|
192.168.1.108
|
|
Web browser access ports:
|
80, 37777
|
|
PC client access ports:
|
37777
|
|
Mobile client access ports:
|
37777
|
|
Port ONVIF:
|
80
|
|
RTSP URL:
|
rtsp://admin:admin@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 - Main stream
rtsp://admin:admin@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 - Sub stream
|
|
Housing:
|
Compact - Metal / Plastic
|
|
Color:
|
White
|
|
Operation temp:
|
-30 °C ... 60 °C
|
|
"Index of Protection":
|
IP67
|
|
Weight:
|
0.438 kg
|
|
Dimensions:
|
180 x 70 x 70 mm
|
