Model
IPC-HFW5502C
Camera
Image Sensor
1/2.5”5Megapixel CMOS
Effective Pixels
2560(H)x1920(V)
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1/3(4)~1/10000s
Min. Illumination
Color: 0. 01Lux/F1.6; 0Lux/F1.6(IR on)
S/N Ratio
More than 50dB
Video Output
1 channel, BNC(1.0Vp-p/75Ω)
Camera Features
Max. IR LEDs Length
30m
Day/Night
Auto(ICR) / Color / B/W
Backlight Compensation
BLC / HLC / DWDR
White Balance
Auto
Gain Control
Auto/Manual
Noise Reduction
3D
Privacy Masking
Up to 4 areas
Lens
Focal Length
4~9mm motorized
Max Aperture
F1.6
Focus Control
Angle of View
H: 82.4°(Wide)~36.1°(Tele)
Lens Type
Motorized /Auto Iris(DC)
Mount Type
Board-inType
Video
Compression
H.264 / MJPEG
Resolution
5M(2560×1920)/3M(2048×1536)/1080P(1920×1080)/720P(1280×720) / D1(704×576) / CIF(352×288) /
Frame Rate
Main Stream
5M(1~12fps)/3M(1~20fps)/1080P/720P(1 ~ 25/30fps)
Sub Stream
D1/CIF(1 ~ 25/30fps)
Bit Rate
H.264H: 32K ~ 8192Kbps
Audio
G.711a / G.711u/ PCM
Interface
1/1 channel In/Out
Network
Ethernet
RJ-45 (10/100Base-T)
Wi-Fi
N/A
Protocol
IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
Compatibility
ONVIF,PSIA,CGI
Max. User Access
20 users
Smart Phone
iPhone, iPad, Android, Windows Phone
Auxiliary Interface
Memory Slot
Micro SD, Max 64GB
RS485
Alarm
2/1 channel In/Out
PIR Sensor Range
General
Power Supply
DC12V(AC24V optional), PoE(802.3af)
Power Consumption
<8.5W
Working Environment
-30°C~+60°C(-H: -40°C~+60°C), Less than 95%RH
Ingress Protection
IP66
Vandal Resistance
Dimensions
ф104mm × 306.7mm
Weight
1.25Kg
