Model
|
DH-NVR4104
|
DH-NVR4108
|
DH-NVR4116
|
System
|
Main Processor
|
Dual-core embedded processor
|
Operating System
|
Embedded LINUX
|
Video & Audio
|
IP Camera Input
|
4 channel
|
8 channel
|
16 channel
|
Two-way Talk
|
1channel Input, 1channel Output, RCA
|
Display
|
Interface
|
1 HDMI, 1 VGA
|
Resolution
|
1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
|
Display Split
|
1/4
|
1/4/8/9
|
1/4/8/9/16
|
OSD
|
Camera title, Time, Video loss, Camera lock, Motion detection, Recording
|
Recording
|
Compression
|
H.264 / MJPEG
|
Resolution
|
720P (1280 x 720) / D1 (704 x 576/704 x 480) / 5Mp (2560 x 1920) / 3Mp (2048 x 1536) / 1080P
|
Record Rate
|
80 Mbps
|
Bit Rate
|
48 ~ 8192kbps
|
Record Mode
|
Manual, Schedule (Regular (Continuous), MD, Alarm), Stop
|
Record Interval
|
1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
|
Video Detection & Alarm
|
Trigger Events
|
Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Buzzer & Screen tips
|
Video Detection
|
Motion Detection, MD Zones: 396 (22 × 18), Video Loss & Camera Blank
|
Playback & Backup
|
Sync Playback
|
1/4
|
1/4/8
|
1/4/8/16
|
Search Mode
|
Time / Date, Alarm, MD & Exact search (accurate to second), Smart search
|
Playback Function
|
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
|
Backup Mode
|
USB Device / Network / Internal SATA burner
|
Network
|
Ethernet
|
1 RJ-45 port (10 / 100Mbps)
|
Network Function
|
DVR, NVS and etc), IP, IP, DHCP, IP, DHCP, DHCP, DDNS, FTP, HTTP, TCP / IP, UPNP, RTSP and UDP. )
|
Max. User Access
|
128users
|
Smart Phone
|
iPhone, iPad, Android
|
Storage
|
Internal HDD
|
1 SATA ports, up to 4TB
|
Auxiliary Interface
|
USB
|
2 ports (2 Rear), USB2.0
|
General
|
Power Supply
|
DC12V / 2A
|
Power Consumption
|
10W (without HDD)
|
Working Environment
|
-10 ° C to + 55 ° C / 10% to 90% RH / 86 to 106 kPa
|
Dimension
(W x D x H)
|
Smart 1U, 205mm × 205mm × 45mm
|
Weight
|
0.5KG (without HDD)
|
