Car DVR with PoE
|
|
Model
|
DHI-NVR0404MF
|
|
Video and audio
|
|
Number of cameras
|
4
|
|
Audio Inputs / Outputs
|
1/1
|
|
Two-way audio communication
|
Supported by
|
|
Display
|
|
Interfaces
|
1 HDMI, 1 VGA, 2 TV
|
|
Resolution
|
1920 × 1080, 1280 × 1024, 1280 × 720, 1024 × 768,
800 × 600
|
|
Layout of windows
|
1/4
|
|
Private Areas
|
up to 4 zones (for each camera)
|
|
Display in the window
|
Camera title, time, video loss, lens close, motion detection, recording
|
|
Recording
|
|
Video / audio compression
|
H.264 / G711 / PCM
|
|
Stream for recording
|
up to 200Mbit / s
|
|
Bitrate
|
48 ~ 8192kbps
|
|
Recording mode
|
Manually, on schedule, on alarm
|
|
Duration of recording
|
1 ~ 120 min (default: 60 min), pre-recording: 1 ~ 30 seconds, post recording: 10 ~ 300 seconds
|
|
Events and anxiety
|
|
Event Actions
|
Recording, PTZ control, start-up bypass, alarm output activation, email sending, FTP data transmission - snapshot and video recording, audible alarm and information output to the monitor
|
|
Detection
|
Motion detection (up to 396 (22 × 18) zones), video loss and lens closure
|
|
Alarm Inputs
|
8
|
|
Alarm Outputs
|
2
|
|
Playback and backup
|
|
Simultaneous Playback
|
1/4
|
|
Search Modes
|
By time and date, alarm, motion detection, per second search
|
|
Playback Functions
|
Play, pause, stop, rewind, fast / slow playback, select next / previous file, full monitor, repeat, backup selection, digital zoom
|
|
Backup
|
Through USB, over a network
|
|
Net
|
|
Interface
|
1 RJ-45 (10/100 / 1000Mbit / s)
|
|
PoE
|
4 ports (IEEE802.3af / at)
|
|
Wireless Interfaces
|
Built-in 3G / 4G / Wi-Fi (optional)
|
|
GPS
|
Built-in module (optional)
|
|
Functions
|
TCP / IP, UDP, DHCP, DDNS, FTP, Email, Alarm
|
|
Maximum number of connections
|
Up to 128 users
|
|
Mobile platforms
|
iPhone, iPad, Android
|
|
Storage
|
|
Internal HDD
|
2 SATA to 4TB each
|
|
Slot for SD card
|
1, up to 128GB
|
|
Additional interfaces
|
|
USB
|
2 ports, USB3.0
|
|
RS232
|
1
|
|
RS485
|
1
|
|
CAN
|
Supported by
|
|
Heater
|
Optional
|
|
G-sensor
|
Supported by
|
|
Power supply
|
|
Food
|
DC 6 ~ 36V
|
|
Consumption
|
up to 15W
|
|
terms of Use
|
|
Working conditions
|
-30 (with heater) ~ + 60 ° C
|
|
Storage conditions
|
-30 ~ + 70 ° C, relative humidity 0 ~ 90%
|
|
Total information
|
|
Dimensions
|
180mm × 208mm × 100mm
|
|
The weight
|
3kg (without HDD)
|
