Model |
DH-PFM886-20 |
Wireless Features |
Wireless Standard |
IEEE802.11 a/n/ac |
Working Frequency |
5745~5825MHz(support frequency to extend, extended range: 4920~6100MHz) |
Wireless Speed |
867Mbps |
Modulation Mode |
OFDM |
Antenna |
External antenna: gain 29dBi |
Output Power |
27dBm (max) |
Receiving Sensitivity |
11a: -91dBm@ 6Mbps
11n: -74dBm@MCS7
11ac: -67dBm@MCS9 |
Transmission Distance |
0-20Km |
Wireless Direction Angle |
Horizontal 6°, vertical 6° |
Hardware |
Power |
1*PoE RJ45(IN: 220V, OUT: 48V/0.5A), |
Power Consumption |
Max. 15W |
Ethernet Port |
1*LAN RJ45(1Gbps) |
Working Temperature |
-30℃~+70℃ |
Storage Temperature |
-40℃~+80℃ |
Working Humidity |
5%~95%RH( no condensation) |
Equipment Dimension |
265×265×47.5mm |
Antenna Dimension |
ɸ600m |
Equipment Weight |
2.4Kg |
Antenna Weight |
6.15Kg |
Protection Level |
IP66 |
Software |
Encryption Type |
WPA-PSK/WPA2/CCMP(AES)/TKIP |
Network Mode |
Route/Network Bridge |
Working Mode |
Access Point/Client/WDS AP/WDS client |
Security Mechanism |
IP/MAC address filtering, hide network name and etc. |
Network Protocol |
TCP/UDP/ARP/ICMP/DHCP/HTTP/NTP |
TDMA Enhancement |
Support(TDMA eliminate hidden nodes influence and greatly improve one-to-many performance) |
Auto ACK Timing Adjustment |
Support(Auto optimize parameter within long-distance communication and make the performance optimal) |
Management and Log |
NTP, Syslog, Telnet, AC, SNMP |
Webpage Configuration Management |
Support webpage configuration, AC remote management and
SNMP management |
Firmware Update |
Support Firmware webpage update and AC remote upgrade |
Bandwidth Flexible Configuration |
10/20/40/80MHz |
