Model
|
DH-DVR5204L
|
DH-DVR5208L
|
DH-DVR5216L
|
|
System
|
|
Main Processor
|
Embedded processor
|
|
Operating System
|
Embedded LINUX
|
|
Video
|
|
Input
|
4 channel, BNC
|
8 channel, BNC
|
16 channel, BNC
|
|
Standard
|
NTSC(525Line, 60f/s), PAL(625Line, 50f/s)
|
|
Audio
|
|
Input
|
4 channel, RCA
|
|
Output
|
1 channel, RCA
|
|
Two-way Talk
|
1 channel Input, 1 channel Output(reuse the audio output channel), BNC
|
|
Display
|
|
Interface
|
1 HDMI, 1 VGA, 1 TV, 1 Spot, BNC
|
|
Resolution
|
1920×1080, 1280×1024, 1280×720, 1024×768
|
|
Display Split
|
1/4
|
1/4/8/9
|
1/4/8/9/16
|
|
Privacy Masking
|
4 rectangular zones (each camera)
|
|
OSD
|
Camera title, Time, Video loss, Camera lock, Motion detection, Recording
|
|
Recording
|
|
Video/Audio Compression
|
H.264 / G.711
|
|
Image Resolution
|
D1/4CIF(704×576/704×480) / HD1(352×576/352×480) / 2CIF(704×288/704×240) / CIF(352×288/352×240) / QCIF(176×144/176×120)
|
|
Record Rate
|
Main Stream:
|
D1/HD1/2CIF/CIF(1~25/30fps)
|
|
Extra Stream
|
CIF/QCIF(1~25/30fps)
|
|
Bit Rate
|
48~3072Kb/s
|
|
Record Mode
|
Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
|
|
Record Interval
|
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
|
|
Video Detection & Alarm
|
|
Trigger Events
|
Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Spot, Buzzer & Screen tips
|
|
Video Detection
|
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
|
|
Alarm Input
|
4 channel
|
8 channel
|
16 channel
|
|
Relay Output
|
3 channel
|
|
Playback & Backup
|
|
Sync Playback
|
1/4
|
1/4/9
|
1/4/9/16
|
|
Search Mode
|
Time/Date, Alarm, MD & Exact search (accurate to second), Smart search
|
|
Playback Functions
|
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
|
|
Backup Mode
|
USB Device / Network
|
|
Network
|
|
Ethernet
|
RJ-45 port (10/100M/1000M)
|
|
Network Functions
|
HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, Alarm Server
|
|
Max. User Access
|
20 users
|
|
Smart Phone
|
iPhone, iPad, Android, Windows Phone
|
|
Storage
|
|
Internal HDD
|
2 SATA ports(2HDDs or 1HDD + 1CD/DVD-RW), up to 8TB
|
|
Auxiliary Interface
|
|
USB Interface
|
2ports (1 Rear), USB2.0
|
|
RS232
|
1 port, For PC communication & Keyboard
|
|
RS485
|
1 port, For PTZ control
|
|
Environmental
|
|
Power Supply
|
DC12V/ 4A
|
DC12V/ 5A
|
|
Power Consumption
|
15W(without HDD)
|
|
Working Environment
|
-10 ~+55°C / 10~90%RH / 86~106kpa
|
|
Dimension(W×D×H)
|
1.5U, 440mm×460mm×68mm
|
|
Weight
|
5.0KG(without HDD)
|
| |
|
|
|
|
|
|
