Angle of view (horzntl, vertl, diagnl)
|
5 degree 10', 3 degree 30', 6 degree 10'
|
|
Lens construction (elements/groups)
|
7/6
|
|
No. of diaphragm blades
|
8
|
|
Minimum aperture
|
32
|
|
Closest focusing distance (m)
|
3.5
|
|
Maximum magnification (x)
|
0.12
|
|
AF actuator
|
USM (1)
|
|
Filter diameter (mm)
|
77
|
|
Max. diameter x length (mm)
|
90 x 256.5
|
|
Weight (g)
|
1,250
|
|
Magnification - Extension Tube EF12 II
|
0.16 - 0.03
|
|
Magnification - Extension Tube EF25 II
|
0.21 - 0.07
|
|
Hard case
|
LH-D29
|
|
Soft case
|
LZ1132
|
|
G.F.Holder III (hood III*)
|
-5
|
|
G.F.Holder IV (hood IV*)
|
-5
|
| |
|
|
AF actuator
|
(1) Mechanical full-time manual focusing built-in.
|
| |
|
| |
*Maximum number of Hood III/IV attachable. In case of zoom lenses, the maximum number applies to the short focal length
|
