Angle of view (horzntl, vertl, diagnl)
|
29 degrees - 10 degrees, 19 degrees 30' - 7 degrees, 34 degrees - 12 degrees
|
|
Lens construction (elements/groups)
|
16/13
|
|
No. of diaphragm blades
|
8
|
|
Minimum aperture
|
32
|
|
Closest focusing distance (m)
|
1.2
|
|
Maximum magnification (x)
|
0.21 (at 200mm)
|
|
AF actuator
|
USM (1)
|
|
Filter diameter (mm)
|
67
|
|
Max. diameter x length (mm)
|
76 x 172
|
|
Weight (g)
|
705
|
|
Magnification - Extension Tube EF12 II
|
0.29 - 0.06
|
|
Magnification - Extension Tube EF25 II
|
0.39 - 0.13
|
|
Lens hood
|
ET-74
|
|
Soft case
|
LZ1224
|
|
G.F.Holder III (hood III*)
|
-2
|
|
G.F.Holder IV (hood IV*)
|
-3
|
|
AF actuator
|
(1) Mechanical full-time manual focusing built-in.
|
| |
|
| |
*Maximum number of Hood III/IV attachable. In case of zoom lenses, the maximum number applies to the short focal lenght
|
