Angle of view (horzntl, vertl, diagnl)
|
74°, 53°, 84°
|
|
Lens construction (elements/groups)
|
13/10
|
|
No. of diaphragm blades
|
8
|
|
Minimum aperture
|
22
|
|
Closest focusing distance (m)
|
0.25
|
|
Maximum magnification (x)
|
0.17
|
|
Distance information
|
Provided
|
|
AF actuator
|
Ring USM¹
|
|
Dust/moisture resistance
|
Yes¹
|
|
Filter diameter (mm)
|
77
|
|
Max. diameter x length (mm)
|
83.5 x 86.9
|
|
Weight (g)
|
650g
|
|
Magnification - Extension Tube EF12 II
|
0.67-0.50
|
|
Magnification - Extension Tube EF25 II
|
NC
|
|
Lens Cap
|
E-77U /E-77II
|
|
Lens hood
|
EW-83K
|
|
Soft case
|
LP1319
|
|
Extenders
|
NC
|
|
Footnotes
|
AF actuator - ¹ Full time Manual focus
|
| |
|
| |
Dust/moisture resistance - ¹ Lenses with dust/moisture resistance are fitted with a rubber ring on the lens mount which may cause slight abrasion of the camera mount. This in no way effects either the lens or camera performance.
|
