Angle of view (horzntl, vertl, diagnl)
29° - 10°, 19°30' - 7°, 34° -12°
Lens construction (elements/groups)
23/19
No. of diaphragm blades
8
Minimum aperture
32
Closest focusing distance (m)
1,2
Maximum magnification (x)
0.21 (at 200mm)
Distance information
Provided
Image stabilizer
4-stops
AF actuator
Ring USM¹
Dust/moisture resistance
Yes
Filter diameter (mm)
77mm
Max. diameter x length (mm)
88.8 x 199
Weight (g)
1490g
Magnification - Extension Tube EF12 II
0.28 - 0.06
Magnification - Extension Tube EF25 II
0.36 - 0.14
Lens Cap
E-77U / E-77II
Lens hood
ET-87
Soft case
LZ1326
Extenders
Compatible
Footnotes
AF actuator - ¹ Mechanical full-time manual focusing built-in.
