Angle of view (horzntl, vertl, diagnl)
|
65 degrees - 6 degrees 50, 46 degrees - 4 degrees 35, 75 degrees - 8 degrees 15
|
Lens construction (elements/groups)
|
23 / 16
|
No. of diaphragm blades
|
8 (circular type)
|
Minimum aperture
|
f/22-38 (f/22-40 for cameras featuring 1/3-stop increments)
|
Closest focusing distance (m)
|
0.7m to infinity (at all zoom focal lengths)
|
Maximum magnification (x)
|
0.06 (Wide); 0.3 (Tele)
|
AF actuator
|
Ring USM
|
Filter diameter (mm)
|
77
|
Max. diameter x length (mm)
|
92 x 184
|
Weight (g)
|
1,670
|
Magnification - Extension Tube EF12 II
|
Compatible
|
Magnification - Extension Tube EF25 II
|
Only compatible in Tele mode
|
Lens hood
|
ET-83G
|
Soft case
|
LZ1324
|
G.F.Holder III (hood III*)
|
Incompatible
|
G.F.Holder IV (hood IV*)
|
6, only compatible at tele
|
|
*Maximum number of Hood III/IV attachable. In case of zoom lenses, the maximum number applies to the short focal length
|
