OPTICAL FEATURES/SPECIFICATIONS
|
| |
|
|
Image size
|
-
|
|
35mm film equivalent focal length (mm)
|
-
|
|
Angle of view (horzntl, vertl, diagnl)
|
20° - 5°10', 14° - 3°30', 24° - 6°10'
|
|
Lens construction (elements/groups)
|
21/16
|
|
No. of diaphragm blades
|
9
|
|
Minimum aperture
|
32-38(40)¹
|
|
Closest focussing distance (m)
|
0.98
|
|
Maximum magnification (x)
|
0.31(at 400mm)
|
|
Distance Information
|
Yes
|
|
Image stabilizer
|
4-stops¹
|
|
AF actuator
|
Ring USM¹
|
| |
|
|
PHYSICAL SPECIFICATIONS
|
| |
|
|
Dust/moisture resistance*
|
Yes
|
|
Filter diameter (mm)
|
77
|
|
Max. diameter x length (mm)
|
94x193
|
|
Weight (g)
|
1640 with tripod mount
|
| |
|
|
ACCESSORIES
|
| |
|
|
Lens cap
|
E-77II
|
|
Lens hood
|
ET-83D
|
|
Lens case/pouch
|
LZ1326
|
|
Rear cap
|
Lens Dust Cap E
|
|
Magnification w/ Extension Tube EF12 II
|
0.38-0.03
|
|
Magnification w/ Extension Tube EF25 II
|
0.46-0.07
|
|
Extender Compatiblity
|
Compatible
|
|
Other Accessories
|
-
|
| |
|
|
SPECIFICATIONS WITH EF 1.4X III
|
| |
|
|
Focal Length
|
140-560
|
|
Maximum Aperture
|
6.3-45 (8-57 at 400mm)
|
|
Maximum Magnification
|
0.44 at 400mm
|
|
AF Possible
|
Yes¹
|
|
IS
|
Yes¹
|
| |
|
|
SPECIFICATIONS WITH EF 2X III
|
| |
|
|
Focal Length
|
200-800
|
|
Maximum Aperture
|
9-64 (11-81 at 400mm )
|
|
Maximum Magnification
|
0.64
|
|
AF Possible
|
Not Possible
|
|
IS
|
Yes¹
|
|
Disclaimers
|
*Lenses with dust/moisture resistance are fitted with a rubber ring on the lens mount which may cause sligth abrasion of the camera mount.
|
| |
This in no way effects either the lens or camera performance.
|
|
Footnotes
|
Minimum aperture - ¹ Minimum aperture if using 1/3stop increments
|
| |
Image stabilizer - ¹ Tested under CIPA standards
|
| |
AF actuator - ¹ Full time Manual focus
|
| |
AF Possible - ¹ AF possible only with EOS-1 series, 7D Mark II, 5D Mark III (with firmware 1.2.1) and EOS 80D.
|
| |
IS - ¹ IS will not work with the following cameras EOS-1, EOS 5, EOS 100, EF-M, EOS 1000/F/n/Fn, EOS 700, EOS 10, EOS RT, EOS 600/630, EOS 850, EOS 750, EOS 620, EOS 650
|
