Scanner Type
|
Flatbed
|
|
Scanning Method
|
CIS (Contact Image Sensor)
|
|
Light Source
|
3-colour (RGB) LED
|
|
Optical Resolution*1
|
4800 x 4800dpi
|
|
Selectable Resolution*2
|
25 - 19200dpi
|
|
Scanning Bit Depth
|
|
|
Grayscale
|
16-bit input
8-bit output
|
|
Colour
|
48-bit input (16-bit for each colour)
48 or 24-bit output (16-bit or 8-bit for each colour)
|
|
Preview Speed*3
|
Approx. 9secs.
|
|
Scanning Speed*4
|
Colour A4 300dpi
|
Approx. 10secs.
|
|
Scanning Speed*5 (Reflective)
|
|
|
Grayscale, B&W
|
4800dpi
|
11.1msec/line
|
|
2400dpi:
|
5.6msec/line
|
|
1200dpi:
|
2.8msec/line
|
|
600dpi:
|
1.4msec/line
|
|
300dpi:
|
2.2msec/line
|
|
Colour
|
4800dpi
|
33.2msec/line
|
|
2400dpi:
|
16.7msec/line
|
|
1200dpi:
|
8.4msec/line
|
|
600dpi:
|
4.3msec/line
|
|
300dpi:
|
2.2msec/line
|
|
Max. Document Size
|
A4, LTR:
|
216 x 297mm
|
|
Scanner Buttons (EZ Buttons)
|
5 buttons (PDF x 2, AUTOSCAN, COPY, SEND)
|
|
Interface
|
USB 2.0 Hi-Speed
|
|
Operating Environment
|
|
|
Temperature
|
5 - 35°C
|
|
Humidity
|
10 - 90% RH (no dew condensation)
|
|
Power Supply
|
Supplied via USB port
|
|
Power Consumption
|
Maximum during operation
|
Approx. 2.5W
|
|
Stand-by
|
Approx. 1.4W
|
|
OFF (Suspend)
|
Approx. 11mW
|
|
Environment
|
|
|
Regulation
|
RoHS (EU, China), WEEE (EU)
|
|
Eco-Label
|
Energy Star
|
|
Dimensions (W x D x H)
|
250 × 365 × 39mm
|
|
Weight
|
Approx. 1.6kg
|
