DIMENSION
|
|
Indoor (W*H*D)(mm)
|
1,030*325*250
|
|
Indoor (W*H*D)(inch)
|
40.6*12.8*9.8
|
|
Outdoor (W*H*D)(mm)
|
810*568*270
|
|
Outdoor (W*H*D)(inch)
|
31.9*22.3*10.6
|
|
Filter
|
|
3M Multi Protection Filter
|
Yes
|
|
Prefilter(washable/anti-fungus)
|
Yes
|
|
Plasma Filter
|
Yes
|
|
Highlights
|
|
Cooling (Min / Rated / Max) T1
|
5.04 KW, 17353 Btu/h
|
|
Heating (Min / Rated / Max) T3
|
4.45 KW , 15194 Btu/h.
|
|
Power Input (Cooling) T1-W
|
1980
|
|
Power Input (Cooling) T3-W
|
2325
|
|
Power Supply
|
1 / 220-240 / 50 - Ø / V / Hz
|
|
Running Current (Cooling) T1-A
|
8.7
|
|
Running Current (Cooling) T3-A
|
10.4
|
|
Starting Current (Cooling) T1-A
|
8.7
|
|
Starting Current (Cooling) T3-A
|
10.4
|
|
Net Weight
|
|
Indoor (kg(lbs))
|
14 (30.9)
|
|
Outdoor (kg(lbs))
|
39 (86.0)
|
|
Operation Range
|
|
Cooling (outdoor) °C(°F)
|
18°C~30°C
|
|
Other Functions
|
|
Additional Refrigerant charge
|
20 g/m
|
|
Circuit Breaker
|
20 A
|
|
Max. Elevation Difference
|
15 (49.2) m(ft)
|
|
Max. Piping Length
|
20 (65.6) m(ft)
|
|
Moisture Removal
|
2.0 l/h
|
|
Refrigerant & Charge
|
R22,850 (30) g(oz)
|
|
Performance
|
|
Air Flow Rate (Indoor, Max)
|
12.6 (445) m3/min(CFM)
|
|
Air Flow Rate (Outdoor, Max)
|
32.0 (1,130) m3/min(CFM)
|
|
EER
|
2.6 T1-W/W , 8.7 T1-Btu/h.W , 1.9 T3-W/W , 6.5 T3-Btu/h.W
|
|
Noise Level © (Indoor,H / M / L / LL)
|
40 / 37 / 34 / dB(A)±3
|
|
Noise Level © (Outdoor, Max)
|
54 dB(A)±3
|
|
Piping Connections
|
|
Liquid Side (mm(in))
|
6.35 (1/4)
|
|
Gas Side (mm(in))
|
12.70 (1/2)
|
